FULL AUTOMATIC NAIL MAKING MACHINE


We manufacturer a series of the full-automatic high speed nail making machines for making all kinds of nails such as common wire nail, strip nails,coil nails etc.
The speed is high up to 600-760 pcs per minute and no doubly that they will replace the tradictional common speed nail making machines very soon.
These wire nail making machine ZDJ-X90, ZDJ-D90, ZDJ-X130, ZDJ-X150 are very popular in the nails making industry all over the world.
Here we listed the specification as below for your reference:

MODEL NO. OEM-ZDJ-X90 OEM-ZDJ-D90 OEM-ZDJ-X150
Max. Dia. of nail 3.5mm 3.5mm 4.5mm
Min. Dia. of nail 2.0mm 2.0mm 2.4 mm
Max. Length of nail 90mm 90mm 150mm
Min. Length of nail 45mm 45mm 70 mm
Power Required  7kw 7kw 11kw
Nail making speed 760pcs/min 760pcs/min 600pcs/min
L*W*H (mm) 2000*1050*1100 2000*1050*1100 2300*1200*1100
Usage Round nails
Coil nails
D head
Paper strip nails
Round nails
Coil nails
Weight  2800kgs 2800kgs 4000kgs
